Home Incubators Yogurt Incubator
Placeholder
Yogurt Incubator (Refrigerated) ₹0.00
Back to products
Oven Universal ( Memmert Type).
Oven Universal ( Memmert Type). ₹0.00

Yogurt Incubator

₹0.00

YOGURT INCUBATOR are one of the finest quality milk processing equipment used prominently is food processing & dairy industries. It is milk processing equipment used for speeding up the bacterial fermentation process if the milk which results in yogurt or dahi. Yogurt is further processed to make many other products like Ghee, shrikhand etc.

Category: Incubators
Share:
  • Description
  • Reviews (0)
Description

APPLICATION



  • Dahi incubator/Yogurt Incubator a milk processing equipment that follows a simple process for making dahi or yogurt wherein the milk is boiled and then cooled to the room temperature. This cooled milk is then mixed with bacterial culture which is used for the milk fermentation. After the thorough mixing of the milk it is then filled in the plastic cups and incubated to 30o35oC for about 2 to 4 hrs.



FEATURES

  • Outer body made up of PCGI steel sheet duly powder coated. Inner chamber and perforated trays made of stainless steel (SS-304).
  • Space between inner chamber and outer wall is filled with high grade insulation for minimal heat dissipation.
  • Bigger sized units mounted on caster wheels for easy portability.
  • Door fitted with heavy duty hinges and door handle ensuring there are no leakages through the door gasket.
  • Synthetic door gasket made of neoprene rubber is fitted to all units instead of asbestos.
  • To work on 220/230V AV, 50/60 Hz supply

TECHNICAL SPECIFICATION



Model No ASI-YINC-1212 ASI-YINC-1414 ASI-YINC-1818 ASI-YINC-1824 ASI-YINC-2424 ASI-YINC-241836 ASI-YINC-2436 ASI-YINC-243636 ASI-YINC-3636
Inner Dimensions (WxDxH)mm 300x300x300 355x355x355 455x455x455 455x455x605 605x605x605 605x455x910 605x605x910 600x900x900 900x900x900
Capacity 28 ltrs 45 ltrs 95 ltrs 125 ltrs 224 ltrs 252 ltrs 336 ltrs 500 ltrs 750 ltrs
Heat Load 0.50 KW 0.50 KW 1.00 KW 1.00 KW 1.50 KW 1.50 KW 1.50 KW 2.75KW 3.0 KW
No. of Shelves 2 2 2 2 2 3 3 3 3
Temperature Range Incubation at 30o-35oC for about 2 to 4 hours.
Forced Convection Available with forced convection system (Standard Features)
Temperature Controller Microprocessor based PID Digital Temperature Indicator cum Controller with LED Display
Display Digital LED with SV and PV display
Regulator Solid state electronic relay with protective heat sink
Safety Device Over temperature limiter switch prevents overheating
