Double wall inside made of thick anodized aluminum/ S. Steel 304 grade and outside Mild steel sheet furnished in durable power coating. The gap of 3” between two walls is fitted with pure white glass wool the door has double viewing to permit observation without disturbing thermal condition. Heating elements are placed in ribs at the bottom and sides. Unique design of ventilation keeps the instrument from being burnt. Fitted with silent air circulating fan for uniform temperature inside the chamber.
SPECIFICATION
| Interior (mm) | 300 X 300 X 300 | 350 X 350 X 350 | 450 X 450 X 450 | 450 X 450 X 605 | 605 X 605 X 605 | 605 X 605 X 900 | 605 X 450 X 900 |
|---|---|---|---|---|---|---|---|
| Capacity (LTR) | 28 | 45 | 95 | 125 | 224 | 336 | 252 |
| Heater load | 400W | 400W | 500W | 700W | 750W | 1.0KW | 1KW |
| Shelves | 2 | 2 | 2 | 2 | 2 | 3 | 3 |
| Temp. Range | Ambient to 70˚C | ||||||
| Temp. Stability | ± 0.5˚C | ||||||
| MOC (Inner) | Made of Stainless Steel (SS-304)/Aluminum | ||||||
| MOC (Outer) | Made of mild steel sheet duly powder coated. | ||||||
| Safety Device | Temperature overshoots High & Low Temperature alarm. | ||||||
| Heater | Kanthal A1 super quality coil shaped heater | ||||||
| Typer | Force convection system. | ||||||
| Temp. Controller | Microprocessor based PID indicator cum controller | ||||||
| Regulator | Solid state electronic relay with protective heat sink | ||||||
| Insulation | Glass wool/Ceramic Blanket | ||||||
| Front door | Glasswool/Mineral wool insulated door with glass window | ||||||
| Power supply | 220/230V A.C single supply; 50Hz | ||||||
| Duty cycle | Continuous | ||||||
| Optional | • Outer S. Steel 304 grade body on customer’s demand. • Inner Acrylic clear door. • Fully automatic PLC based control system. |
||||||
