FEATURES:-
- Refrigerated insulation & freezing in one unit.
- Better mineral and puff insulated to keep the surface temperature of body comfortable & avoid cooling loss.
- Silent energy saving kirloskar/ Tecumseh compressor, designed to circulate uniform air throughout the chamber with better imported coil condenser copper coil, improve temperature distribution.
- Polish 304 grade S. Steel interior corrosion resistant long life operation having adjustable shelves to make more space for different height.
- KANTHAL’ A-1’ tubular heater is fitted for better accuracy.
- Safety controllers are provided with the digital temperature controller cum indicator.
- Full Features with Microprocessor Based PID temperature controller cum indicator with volt meter.
- Choose among the model with window front glass door or inner Perspex/Acrylic sheet full view door to observe the taste process inside the incubator as desired while keep temperature uninterrupted.
- Angle iron frame at bottom with caster wheel for easy movement.
- Fitted with 2 Nos. Fan (One for cooling & one for heating inside the chamber).
TECHNICAL SPECIFICATION & ODERING INFORMATION:-
| Volume | 113 Liters | 173 Liters | 238 Liters | 340 Liters | 425 Liters |
|---|---|---|---|---|---|
| Capacity (LTR) | 4 cu. Ft. | 6.1 cu. Ft. | 10 cu. Ft. | 12 cu. Ft. | 15 cu. Ft. |
| Shelves | 2 | 3 | 3 | 3 | 3 |
| External Chamber | MS / SS 304 | ||||
| Internal Chamber | Stainless Steel 304 (Optional SS 316) | ||||
| Temperature Range | 5°C to 50°C | ||||
| Temp. Accuracy | ± 0.5˚C or Better | ||||
| Display | Backlit LED Display | ||||
| Temperature control | Microprocessor P.I.D controller On / Off compressor control PT 100 sensor |
||||
| Door | Solid insulated door (with glass & without glass) w/ lock | ||||
| Shelves | Stainless steel Shelves (2 to 5), removable | ||||
| Refrigerant | R134a / CFC Free | ||||
| Power | 220 Volts | ||||
| Compressor | Kirlokskar/ Tecumseh Model as per size requirement. | ||||
| Power supply | 220/230V A.C single supply; 50Hz | ||||
| Duty cycle | Continuous | ||||
| Optional | – Caster wheels – Humidity system – Light system by interior illumination w/ 3 fluorescent tubes – Timer 0-24 hours for regulating cycle’s illumination condition – Arrangement for incubation of CO2 Air Mixture – Combined Electronic Digital Temperature & humidity controller – Automatic Voltage Stabilizer of 3 KVA – Certifications (IQ / OQ / DQ / PQ) |
||||
