FEATURES
- Precision Microprocessor PID Controller provides +1.0OC uniformity, +1.0OC accuracy, temperature range from ambient to 99OC.
- Easy to use membrane touch type front mount controller with timer, alarm and auto-tuning function.
- Precise temperature control upto 99OC.
- Corrosion resistant Stainless Steel Bath (304 grade).
- Industrial grade energy efficient heaters reduces power bills drastically.
- Double walled construction.
- Space between the wall is fitted with special grade mineral wool in order to avoid thermal losses.
- Drain plug is also fitted to the unit for user convenience.
- The stirring arrangement consists of a FHP motor SS stirring shaft.
- (Inner): Inner bath chamber & lid made of stainless steel (SS 304 grade)
- (Outer): Outer chamber is made of mild steel duly power coated.
- To work on 220/230V AC supply
OPTIONS
- Spare shaking tray with lotus clamps or test tube rack.
- Digital RPM/SPEED Meter
TECHNICAL SPECIFICATION
| Model No. | ASI-WB-MC-2 | ASI-WB-MC-3 |
|---|---|---|
| Internal Dimensions (LXWXD) | 300 x 300 x 175mm x 2 baths | 300 x 300 x 175mm x 3 baths |
| Capacity | 18 ltrs x 2 baths | 18 ltrs x 3 baths |
| Heater Load | 700 w x 2 baths | 700 w x 3 baths |
| Temperature Controller | Microprocessor Based PID Digital Temperature Indicator-cum-Controller | |
| Temperature Range | From ambient to + 5oC to 80oC | |
| Temperature Accuracy | ±0.5 ˚C | |
| Temperature Sensor | RTD (Pt-100) | |
| Timer | Digital display in min/hr | |
| Alarm | End of cycle buzzer | |
| Temperature Display | With Digital LED Display for Set Value (SV) & Process Value (PV) | |
