SALIENT FEATURES & CONSTRUCTION:-
- It is a compact bench top model unit
- The shaker is mounted on ball bearing crankshafts to give an orbital circular motion to the flasks.
- The rotator has covered metal platform Size 300 x 300 mm with spring, holder clamp.
- The diameter of the orbit is approximately – 40 mm
- Compact counter balanced drive mechanism ensures high stability and reliability even in continuous operation & uneven load distribution.
- Speed range is 70 – 210 RPM.
- High Speed (Model) range is up to 350 RPM.
- Fitted with heavy duty motor having variable speed.
- Speed can be controlled through variable speed regulator knob.
- Control panel plate fitted on the front having indicator lamp ON/OFF switch & speed regulator knob.
- Supplied complete with cord & plug to work on Single Phase 220 / 230 volts A.C. supply.
TECHNICAL SPECIFICATIONS & ORDERING INFORMATION:-
| Plate Form Size (In mm) | 300 x 300 |
|---|---|
| Can Accommodate | VDRL Plates, Small Flasks, Bottles & Beakers |
| Speed Range in Regular Model | 70 to 210 RPM |
| Speed Range in High Speed Model | 70 to 350 RPM (Approximate) |
| Electric Supply | Single Phase 220 / 230 volts A.C. supply. |
