APPLICATION:-
Sterilization & storage for pharmaceutical, agriculture, medical & food industries, education institute, Bio-tech, laboratory requiring controlled temperature above ambient.
TECHNICAL SPECIFICATION & ORDERING INFORMATION:-
| Interior (mm) | 300 X 300 X 300 | 350 X 350 X 350 | 450 X 450 X 450 | 605 X 605 X 605 | 605 X 605 X 900 | 605 X 450 X 900 | |
|---|---|---|---|---|---|---|---|
| Capacity (LTR) | 28 | 45 | 95 | 224 | 336 | 252 | |
| Heater load | 1.5KW | 1.5KW | 2.0 KW | 3.0 KW | 3.5 KW | 3.0 KW | |
| Shelves | 2 | 2 | 2 | 2 | 3 | 3 | |
| Temp. Range | Ambient to 300˚C | ||||||
| Type | Force convection system. | ||||||
| Temp. Controller | Microprocessor based PID temperature indicator cum controller with LED display. | ||||||
| Temp Accuracy | ± 0.5˚C | ||||||
| Regulator | SSR Temperature limiter with protective heat sink. | ||||||
| Safety Device | Over Temperature limiter switch. | ||||||
| Power supply | 220/230V,50Hz | ||||||
| Heater | Kanthal A1 super quality coil shaped heater | ||||||
| Optional | • Communication Port for PC Interface, complete with Communication cable. • Double Colour Gate, top & control panel (On customer Demand/request). |
||||||
